Heavy Duty Forged Steel Casters

Unbreakable body, with steel ring assembly. Self locking ball system. No King Pin, SIngle ball race, fitted with grease nipple, dust proof by nylon washer. Wheel lock available.
SRT, UHMW-PE FR, CI, PU, CPU, CNY wheels can be assembled in these brackets. Recommended where floor condition is not good. Can withstand against occasional shock load.

Available Sizes

Wheel Size
D X W		 Overall Height Offset Swivel Caster (mm) Load Carrying Capacity Symbol
UHM BRT CPUCI CI
100 x 50 155 40 300 – 225 400
150 x 50 205 50 550 135 450 500
200 x 50 255 60 800 170 550 600
200 x 75 255 60 1050 200 – 700
250 x 50 305 70 950 250 550 600
250 x 75 305 70 1300 – – 700
300 x 50 355 50 1000 300 600 650
300 x 75 355 80 1410 350 700 750

Code Reading / Ordering Example:
Heavy Duty, Forged Steel, Plate Type, UHMW-PE, Size 150 x 50 Swivel with Brake.
HD FS PT/UHM/150×50/SBK
